FOLIANT Gemini 400 NG-S

The FOLIANT Gemini 400 NG-S is a semiautomatic high pressure laminating machine (laminator and separator) developed for a digital printing machines outputs lamination. The machine is equipped with a pneumatic pressure system of laminating rollers with an easy thrust control. A small compressor is integrated inside the machine frame. The machine has been designed with an operating width of 380 mm and it represents an ideal choice for professional single side lamination in digital shops and all other printing shops, printing and processing sheets up to B3+ size (the largest format is 38 x 58 cm, with a special option even 38 x 66 cm). Maximum speed is up to 15 meters/min.

The machine’s main feature is a pneumatic pressure system in a heavy duty mechanism enabling to achieve a very high working pressure, one single phase 220 – 240 V supply cable, a small integrated compressor inside the machine frame (i.e. no external source of  pressured air is required), a nice design and an easy machine operation. The machine is supplied with a modular stand covered with a nicely designed side panels as a standard accessory. An RU 400 Reception Unit and/or a Jogger 400 for storing the laminated sheets can be supplied as an option. The machine requires a minimum floor space of 74 x 220 cm including the Jogger.

Laminator

The FOLIANT Gemini 400 NG-S laminator maximum sheet size is 38 x 58 cm. The option allows laminating sheets of maximum size 38 x 66 cm. The minimum sheet size is 20 x 30 cm (A4).
The roll of a film is mounted on an easy handle shaft with a film tension control breaker. The shaft capacity is up to 3000 m of the 24 - 31 microns film. The film holder unit is equipped with a trim slitter and a perforating wheel.
The laminating process is done between two laminating rollers - a highly polished chrome roller, and a lower hard rubber pressure roller. The laminating roller is heated with an infra-red heating spiral, with a sensitive contact temperature sensor. The pressure is pneumatically adjustable to achieve an extra high pressure between the laminating rollers. A small compressor is integrated inside the machine frame.

The laminating unit is equipped with an adjustable twin decurl unit:

  • With a decurl blade for offset printed sheets decurling
  • With a decurl roller for digital printed sheets decurling (to prevent scratches on sheets printed on both sides by digital print with sensitive inks).

Feeding

The FOLIANT Gemini 400 NG-S is a semiautomatic machine. The feeding is manual. The laminating unit is equipped with a synchronized feeding conveyor and an adjustable side guider for an easy manual loading..

Separator

The belt separator (sheeter) is equipped with a separating roller and a deflection wheel. The separated sheets are delivered into a reception unit or a vibrating jogger (options).

Laminating films

The machine laminates the BOPP films (23 – 42 microns). The Nylon films (max 35 microns) can be laminated with the optional module integrated inside the machine separator.

FOLIANT Gemini 400 NG-S

ParameterValue
Maximal Speed
single side 15 m/min
Feeding System
Manual
Overlaps
Separation
Automatic
Paper Weight
115–350 g/m²
Main Roller Pressure System
Pneumatic
Compressor
Included
Minimal Sheets Size (w×l)
20×30 cm
Maximal Sheets Size (w×l)
38×58 cm
Maximal Performance
1200 B3 / hod.
Temperature Control
80–140 °C, Warming Up Time 5 min
Power Supply
230 V AC, 50-60 Hz
Power
2800 W
Mechanical Parameters
Floorspace (w×l) 74×220 cm, Weight: 185 kg
Modular Stand
Standard
Pallet Stacker
Non-sticky pressure roller
Air Shaft
